comp_scan

在模块中定义组件，通过该方法可以实现各模块中组件分别自动布线操作。

首先我们需要定义模块:

blocks = [
    Alignment(
        waveguide_type=TECH.WG.FWG.C.WIRE,
    ),
    Title(
        "TEST TITLE",
        layer=TECH.LAYER.LABEL_DRW,
    ),
    Block(get_ring_resonator_with_terminator(25)),
    Blank(left=0, right=1),
    Block(
        get_ring_resonator_with_terminator(50),
        repeat=3,
    ),
    Block(
        get_ring_resonator_with_terminator(75),
        repeat=3,
    ),
    Block(get_ring_resonator_with_terminator(90), bend_factories=bend_factories),
    Blank(left=0, right=1),
    Block(
        RingFilter(
            ring_radius=25,
            waveguide_type=TECH.WG.FWG.C.WIRE,
        ),
        repeat =3,
    ),
    Block(
        RingResonator(ring_radius=90, ring_type=TECH.WG.FWG.C.WIRE),
        repeat=3,
    ),
]

其中，组件部分所调用的函数定义如下:

from gpdk.components.fixed_terminator_te_1550.fixed_terminator_te_1550 import Fixed_Terminator_TE_1550
from gpdk.components.ring_filter.ring_filter import RingFilter
from gpdk.components.ring_resonator.ring_resonator import RingResonator
from gpdk.routing.extended.extended import Extended
from gpdk.technology.waveguide_factory import EulerBendFactory
from gpdk.components.grating_coupler.grating_coupler import GratingCoupler

def gc_factory(at: fp.IRay, device: fp.IDevice):
    gc = GratingCoupler()  # type: ignore
    return gc, "op_0"

def bend_factories(waveguide_type: fp.IWaveguideType):
    if waveguide_type == TECH.WG.FWG.C.WIRE:
        return EulerBendFactory(radius_min=35, l_max=35, waveguide_type=waveguide_type)
    elif waveguide_type == TECH.WG.SWG.C.EXPANDED:
        return EulerBendFactory(radius_min=55, l_max=35, waveguide_type=waveguide_type)
    elif waveguide_type == TECH.WG.SWG.C.WIRE:
        return EulerBendFactory(radius_min=45, l_max=35, waveguide_type=waveguide_type)
    return waveguide_type.bend_factory

def get_ring_resonator_with_terminator(ring_radius: float):
    terminator = Fixed_Terminator_TE_1550(waveguide_type=TECH.WG.FWG.C.WIRE)
    ring_resonator = RingResonator(ring_radius=ring_radius, ring_type=TECH.WG.FWG.C.WIRE)
    # fp.plot(ring_resonator)
    return Extended(
        device=fp.Connected(
            joints=[ring_resonator["op_2"] <= terminator["op_0"]], ports=[ring_resonator["op_0"], ring_resonator["op_1"], ring_resonator["op_3"]]
        ),
        lengths={"*": 20},
    )

def term_factory(at: fp.IRay, device: fp.IDevice):
    from gpdk.components.fixed_terminator_te_1550.fixed_terminator_te_1550 import Fixed_Terminator_TE_1550

    instance = Fixed_Terminator_TE_1550().h_mirrored()  # type: ignore
    return instance, "op_0"

调用comp_scan方法实现自动布局布线:

library += CompScan(name="comp_scan", spacing=255, width=2000, blocks=blocks, fiber_coupler_factory=term_factory)
library += CompScan(name="comp_scan", spacing=255, width=2000, blocks=blocks, fiber_coupler_adapter=Fixed_Terminator_TE_1550())
library += CompScan(name="comp_scan", spacing=255, width=2000, blocks=blocks, bend_factories=bend_factories, fiber_coupler_factory=gc_factory)
library += CompScan(
    name="comp_scan",
    spacing=255,
    width=2000,
    blocks=blocks,
    bend_factories=bend_factories,
    waveguide_type=TECH.WG.SWG.C.EXPANDED,
    bend_factory=TECH.WG.SWG.C.WIRE.bend_factory,
    connection_type=TECH.WG.MWG.C.WIRE,
    fiber_coupler_factory=gc_factory,
)

最后生成版图文件:

gds_file = Path(__file__).parent / "local" / Path(__file__).with_suffix(".gds").name
library = fp.Library()
fp.export_gds(library, file=gds_file)

最终生成的版图文件如下图所示：
